| Product name |
SIVA 532 |
SIVA 355 |
| Laser medium |
Nd:YAG |
Nd:YAG |
| Oscillator type |
Second harmonic generation |
Third harmonic generation |
| Wavelength |
532nm |
355nm |
| Average power |
15W@10kHz |
5W@8kHz |
| Repetition rate |
1-50kHz |
1-20kHz |
| Pulse duration |
60-150ns@10kHz |
40-80ns@8kHz |
| Pulse energy |
≥1mJ@10kHz |
≥0.6mJ@6kHz |
| Energy stability |
3%rms |
4%rms |
| Output energy stability |
±3% |
±3.5% |
| Beam diameter |
1.5mm±20% |
1mm±20% |
| Spatial beam quality |
M2<4 |
M2<2 |
| Divergence |
≤1mrad |
≤1mrad |
| Size |
W230×D470×H125 mm |
W230×D570×H125 mm |
| Weight |
16kg |
20kg |
| Power supply |
100V×2 |
100V×2 |
| Electrical power |
20A |
20A |
|
 |
 |
* Specifications in this document are subject to change without notice.
|
|
|
