| ■RⅡX,RⅡY(Specifications) |
 |
|
|
|
|
|
|
|
|
| Product name |
RⅡX |
RⅡY |
| Wavelength |
1.3μm |
1.064μm |
| Output power（Fiber delivery） |
500mW |
1W |
| Noise |
<0.5%rms |
<0.5%rms |
| Long-term power stability |
<±2% (2hours) |
<±5% (2hours) |
| Isolation |
>40dB |
>35dB |
| Polarization ratio |
Linear > 100:1 |
Linear > 100:1 |
| Stability |
<2%rms |
<5%rms |
| Optical fiber |
PANDA fiber |
PANDA fiber |
| Size |
W130×D455×H653 mm(include fiber) |
| Power consumption |
AC100-240V < 500VA |
| Impact |
30 G max |
| Laser product class |
Class 4 laser product |
|
Laser Specifications
|
|
Laser beam with transversely lowest mode.
|
|
|
External control is available in the standard model
|
* Specifications in this document are subject to change without notice.
|
|
|
|
|
|
|
 |
|
|
|
|
