■SPICA(Specifications) SPICA Specifications Product name SPICA1064 SPICA532 -YAG SPICA532 -YVO4 SPICA355 -YAG SPICA355 -YVO4 SPICA266 -YAG SPICA266 -YVO4-HR Laser material Nd:YAG or Nd:YVO4 Nd:YAG Nd:YVO4 Nd:YAG Nd:YVO4 Nd:YVO4 Nd:YVO4 Oscillator type AOQ-switch SHG SHG THG THG FHG FHG Wavelength 1064nm 532nm 532nm 355nm 355nm 266nm 266nm Average power 5W 2.5W @ 10kHz 2.5W @ 25kHz 500mW @ 4kHz 500mW @ 25kHz 200mW @ 20kHz 120mW @ 60kHz Repetition rate 1-100kHz (resolution:1kHz) 1-50kHz (resolution:1kHz) 1-100kHz (resolution:1kHz) 1-50kHz (resolution:1kHz) 1-100kHz (resolution:1kHz) 1-100kHz (resolution:1kHz) Pulse duration 10-25ns @ 10kHz 10-25ns @ 10kHz 10-25ns @ 25kHz 10-25ns @ 4kHz 10-25ns @ 25kHz 5-15ns @ 20kHz 20-40ns @ 60kHz Pulse energy 500μJ @ 10kHz 250μJ @ 10kHz 80μJ @ 25kHz 125μJ @ 4kHz 20μJ @ 25kHz 10μJ @ 20kHz 2μJ @ 60kHz Stability of pulse energy 3％ rms 3％ rms 3％ rms 3％ rms Stability of output power ±1.5％ ±1.5％ ±1.5％ ±1.5％ Beam quality M2<1.5 M2<1.5 M2<1.5 M2<1.5 Space mode TEM00 TEM00 TEM00 TEM00 Divergence <1mrad(Option) <1mrad(Option) <1mrad(Option) <1mrad(Option) Stability of output power as temparature change 1％/℃ @ 25〜35℃ 1％/℃ @ 25〜35℃ 1％/℃ @ 25〜35℃ 1％/℃ @ 25〜35℃ Pointing stability <15μrad/℃ <15μrad/℃ <15μrad/℃ <15μrad/℃ Shock resistance 15G max 15G max 15G max 15G max Output guarantee 1year (8,760hours) 6,000hours(Non crystal replacement) 5,000hours(Non crystal replacement) Laser product class Class 4 laser product * Specifications in this document are subject to change without notice. Outline
